Chapter 9 Analog Output Option Board (XBO-DA02A)
(1) Module Ready/Channel Error information ( ( ) is for IEC types, y: slot No.)
(a) U0y.00.F(%UX0.y.15): It will be ON when PLC CPU unit is powered or reset with the condition
that an analog option board has prepared to convert.
(b) U0y.00.0(%UX0.y.0): It is the flag which displays error status of each channel in the analog option
board.
bit15
bit14
bit13
bit12
bit11
bit10
bit9
bit8
bit7
bit6
bit5
bit4
bit3
bit2
bit1
bit0
-
-
-
-
-
-
-
-
-
-
-
U0.00
UW0..0)
Error occurrence
information
Bit On (1): error
Bit Off (0): Normal


-
-
-
Module READY
Bit On (1): Normal
Bit Off (0): error
(2) Channel operation information ( ( ) is for IEC types, y: slot No.)
(a) This area is used to display the channel being used and channel error information.
bit15 bit14 bit13
bit12
bit11
bit10
bit9
bit8
bit7
bit6 bit5 bit4 bit3 bit2 bit1 bit0
- -
CH1 CH0
------
U0.01
UW0..1)
Operating CH
information
Bit On (1): operating
Bit Off (0): stop
- --
-
CH1
CH0
CH error information
Bit On (1): error
Bit Off (0): normal
(3) Output setting ( ( ) is for IEC types, y: slot No.)
(a) Each channel can be specified enable/disable the analog output.
(b) If the output is not specified, output of all the channels will be disabled.
bit15 bit14
bit13 bit12 bit11 bit10
bit9 bit8
bit7 bit6
bit5
bit4
bit3 bit2
bit1
bit0
CH1 CH0
------
U0.06
UW0..6)
Output setting
Bit On (1): enable output
Bit Off (0): disable output
---
- --
--

(4) Digital input ( ( ) is for IEC types, y: slot No.)
(a) Digital input value can be selected and used within the range of unsigned value (0~4047), signed
value (-2000~2047), precise value and percentile value (0~1011) based on input type.
(b) If the digital input value is not specified, it will be set to 0.
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
Output CH0 input value
U0.07
UW0..7)
Output CH1 input value
U0.08
UW0..8)



