1. Product Profile
1.1 Overview
The C32 lidar realizes 360° three-dimensional high-speed scanning with 32
dense laser beams. It reaches a detection distance of up to 150 m, measurement
accuracy of ±3 cm, and a minimum vertical angular resolution of 1°. This lidar
sensor is widely used in unmanned driving, automotive ADAS, intelligent
transportation, service robot, logistics, surveying and mapping, security, industry,
ports and other fields.
1.2 Mechanism
The C32 mechanical lidar adopts the Time of Flight method. The lidar starts
timing (t1) when the laser pulses are sent out. And when the laser encounters
the target object and the light returns to the sensor unit, the receiving end stops
timing (t2).
Distance = Speed of Light*(t2 – t1)/2
Figure 1.1 Time of Flight
1.3 Specifications
Table 1.1 Specifications of C32
