Lu UNO - ÜNO Wiring Diagram

12
GYM CONFIGURATION
ÜNO wiring diagram
Top view
Connect modules 1, 2, 3 and 4 using this diagram
120 Volts cable
HDMI cable
XLR Speakers cable
USB Camera cable
DMX Lighting cable
Network cable
(not included)
01
02
03
04
05
06
10’ (3 m) et 25’ (4,5 m) IEC
65’ (20 m)
25’ (7,5 m)
50’ (15 m)
30’ (10 m) et 15‘ (4,5 m)
As required
01
01
01
0106
01
04
05
02
LightingProjector
Heart
Top view
