Lu UNO - Connection - Cables (H)

26
Plug the Cat5 network cable into the computer’s network jack.
Plug the Heart power cable into the power outlet.
Bring the USB, HDMI, and DMX cables to the light module, attaching them to the structure.
Connect the USB extension cable to the camera’s USB cable.
Unscrew the Philips screw on the light module grommet, insert the cables, and plug the DMX cable into the
connector marked with the bulb-and-wire icon. Then attach the loose USB cable to the inside of the light
module.
Unscrew the Philips screw on the projector-side grommet of the light module and pass the HDMI cable
through the module.
Plug the 25’ (7.5 m) XLR cable from one of the speakers into one of the “IN” ports, then pass the cable
through the grommet in the lighting module to the projector.
Connect the 6’ (1.8 m) XLR cable to the “OUT” port of the same speaker and plug the other end of the cable
into the “IN” port of the second speaker. Secure the cable with plastic zip ties.
To power the projector, plug the IEC cable into the power bar inside the lighting module, then pass the cable
through the grommet toward the projector.
Gather the HDMI, DMX, USB, and power cables and attach them to the structure.
Reinstall the grommet plates with the Philips screws that you removed in steps 05 and 06.
Before moving to the projector, install the light module cover by lifting the cover up and inserting the pin into
the hinge mechanism.
Close the cover and secure it to the hinge mechanism (with two M5 x 25 nuts using an 8 mm socket)
and at the corners with the M5 x 30 nuts using a 3 mm hex screwdriver by lifting the corner with
one hand.
Run the cables along the building walls to the projector.
02
14
12
05
09
03
13
06
10
04
08
07
11
CONNECTION - CABLES (H)
01
Connect the cables, as follows :
17
15
16
Plug the IEC cable into the projector.
Plug the HDMI cable into the HDMI 1 port on the projector.
Plug the XLR cable into the red connector in the projector case.
