ND30PNET-09 - User's Manual
18
4
Voltage transformer primary
1 .. 1245183 V
100
5
Voltage transformer secondary
0.1 .. 01000.0
100.0
6
Current transformer primary
1…20000
5
7
Current transformer secondary
1...1000
5
8
Damend integ. time
15 min, 30 min, 60 min
Averaging time of
active power P DMD,
apparent power S
DMD, current I DMD
15 min
9
AVG synchronization
none, with RTC
Averaging synchronized with
real time clock
none
10
PT100 resist on inp 1
0000.00
Resistance value in 
0.00 
11
PT100 resist on inp 2
PT100
0000.00
Resistance value in 
0.00 
12
Voltage connector 2
U1, U2, U3
U1
13
Voltage connector 5
U1, U2, U3
U2
14
Voltage connector 8
U1, U2, U3
U3
15
Current connector 1-3
I1,-I1,I2,-I2,I3,-I3
I1
16
Current connector 4-6
I1,-I1,I2,-I2,I3,-I3
I2
17
Current connector 7-9
I1,-I1,I2,-I2,I3,-I3
I3
18
Delete energy counters
No, active, reactive,
apparent, all
No
19
Delete demand values
No, Yes
No
20
Default parameters
No, Yes
No
During parameter changes, it is checked if the value is within the range. If the value has been set
out of range, the value is set to the maximum value (the value is too high) or the minimum (the
value is too little).
In order to configure ND30PNET meter the user can also use free eCon software
available at www.lumel.com.pl.
