ND30PNET-09 - User's Manual
41
Alarm output 2 - lower value of switching condition 2 of
input nominal range
Alarm output 2 - upper value of switching condition 2 of
input nominal range
Alarm output 2 – delay of condition 2 activation
Alarm output 2 – delay of condition 2 deactivation
Alarm output 2 – lock of condition 2 reactivation
Alarm output 2– signaling condition 2 occurrence
Alarm output 2 - quantity for condition 3 (c3)
(code acc. to table 8)
Alarm output 2 – type for condition 3: 0 – n_on, 1 – noFF, 2
– on, 3 – oFF, 4 – H_on, 5 – HoFF, 6 – 3non, 7 – 3noF,
8 – 3_on, 9 – 3_oF
Alarm output 2 - lower value of switching condition 3 of
input nominal range
Alarm output 2 - upper value of switching condition 3 of
input nominal range
Alarm output 2 – delay of condition 3 activation
Alarm output 2 – delay of condition 3 deactivation
Alarm output 2 – lock of condition 2 reactivation
Alarm output 2 – signaling condition 2 occurrence
Constant output 1 - quantity at the output
/ code acc. to tab.8 /
Constant output 1 - type: 0 – (0...20) mA; 1 – (4…20) mA;
Constant output 1 - lower value of input range in
[ ‰]
of
nominal input range
Constant output 1 - upper value of input range in
[ ‰]
of nominal input range
Constant output 1 - lower value of current output range
(1 = 10uA)
Constant output 1 - upper value of current output range
(1 = 10uA)
Constant output 1 - manual activation:
0 – normal operation, 1 – value set from register 4096, 2-
value set from register 4097
Address on the Modbus network.
Transmission mode: 0->8n2, 1>8e1, 2->8o1, 3->8n1
Transmission speed: 0->4800, 1->9600
2->19200, 3->38400, 4->57600, 5->115200
Update the change of transmission parameters
Third and second byte (B3.B2) of meter IP address, format IPv4:
B3.B2.B1.B0
First and zero byte (B1.B0) of meter IP address, format IPv4:
B3.B2.B1.B0
