ND30PNET-09 - User's Manual
42
Third and second byte (B3.B2) of meter subnet mask address,
mask format: B3.B2.B1.B0
First and zero byte (B1.B0) of meter subnet mask address, mask
format: B3.B2.B1.B0
Third and second byte (B3.B2) of meter default gateway
address, format: B3.B2.B1.B0
First and zero byte (B1.B0) of meter default gateway address,
format: B3.B2.B1.B0
Third and second byte (B3.B2) of meter DNS address, format
IPv4: B3.B2.B1.B0
First and zero byte (B1.B0) of meter DNS address, format IPv4:
B3.B2.B1.B0
Ethernet interface baud rate:
0 – automatic selection of baud rate
1 – 10 Mb/s
2 – 100 Mb/s
Memorizing new parameters of Ethernet interface and re-initiating
the interface
0 – no changes,
1 – memorizing new parameters and re-initiating Ethernet
interface,
Menu language: 0-ENG, 1-PL, 2-DE
Recording standard parameters (with reset of energies and min and
max averaged parameters) ,
Switching values of alarm conditions recorded in registers 4036, 4037, 4054, 4055, 4067, 4068,
4076, 4077, 4085, 4086 are multiplied by 10, e.g. 100% value should be written "1000".
The lower and upper input range values of the constant output recorded in the registers
4094, 4095 are multiplied by 10, e.g. 100% value should be written "1000".
The lower and upper current output range values recorded in the registers 4096, 4097 are
multiplied by 100, e.g. 20 mA should be written "2000".
Table 17
Register 1 of programmable read-only register group
Register 2 of programmable read-only register group
Register 3 of programmable read-only register group
Register 4 of programmable read-only register group
Register 5 of programmable read-only register group
Register 6 of programmable read-only register group
Register 7 of programmable read-only register group
Register 8 of programmable read-only register group
