ND30PNET-09 - User's Manual
49
Status register 5 (address 4419, R):
Bit 8 – “1” – alarm 1, condition 3 for L3 phase active
Bit 7 – “1” – alarm 1, condition 3 for L2 phase active
Bit 6 – “1” – alarm 1, condition 3 for L1 phase active
Bit 5 – “1” – alarm 1, condition 2 for L3 phase active
Bit 4 – “1” – alarm 1, condition 2 for L2 phase active
Bit 3 – “1” – alarm 1, condition 2 for L1 phase active
Bit 2 – “1” – alarm 1, condition 1 for L3 phase active
Bit 1 – “1” – alarm 1, condition 1 for L2 phase active
Bit 0 – “1” – alarm 1, condition 1 for L1 phase active
Status register 6 (address 4420, R):
Bit 8 – “1” – alarm 2, condition 3 for L3 phase active
Bit 7 – “1” – alarm 2, condition 3 for L2 phase active
Bit 6 – “1” – alarm 2, condition 3 for L1 phase active
Bit 5 – “1” – alarm 2, condition 2 for L3 phase active
Bit 4 – “1” – alarm 2, condition 2 for L2 phase active
Bit 3 – “1” – alarm 2, condition 2 for L1 phase active
Bit 2 – “1” – alarm 2, condition 1 for L3 phase active
Bit 1 – “1” – alarm 2, condition 1 for L2 phase active
Bit 0 – “1” – alarm 2, condition 1 for L1 phase active
Table 21
Address
of register
Ope-
ration
s
Range
Description
Default
4500
RW
0…65535
2 first signs of the Profinet device name in the system
:
:
RW
:
:
:
:
4619
RW
238;239 sign of the Profinet device name in the system
4620
RW
0.1
Memorizing new parameters of Profinet
interface and re-initiating the interface
0 – no changes,
1 – memorizing new parameters and re-initiating Profinet
interface,
0
Table 22
Address of
16 bit
registers
2x16 1032/
2x16 3210
Address
of 32-bit
registers
Operations
Description
Unit
3Ph
/ 4W
3Ph
/
3W
1Ph
/ 2W
6000/8000
7500
R
Voltage of L1 phase
V
 
x
 
6002/8002
7501
R
Current of L1 phase
A
 
 
 
6004/8004
7502
R
Active power of L1 phase
W
 
x
 
6006/8006
7503
R
Reactive power of L1 phase
VAr
 
x
 
6008/8008
7504
R
Apparent power of L1 phase
VA
 
x
 
6010/8010
7505
R
Factor of active power of L1 phase (PF1=P1/S1)
-
 
x
 
6012/8012
7506
R
tg factor of L1 phase (tg=Q1/P1)
-
 
x
 
6014/8014
7507
R
THD U1*
%
 
x
 
6016/8016
7508
R
THD I1
%
 
x
 
6018/8018
7509
R
Voltage of L2 phase
V
 
x
x
6020/8020
7510
R
Current of L2 phase
A
 
 
x
6022/8022
7511
R
Active power of L2 phase
W
 
x
x
6024/8024
7512
R
Reactive power of L2 phase
VAr
 
x
x
6026/8026
7513
R
Apparent power of L2 phase
VA
 
x
x
6028/8028
7514
R
Factor of active power of L2 phase (PF2=P2/S2)
-
 
x
x
