out2
Function of
output 2
off
off: without function
Y: control signal - heating
or control signal „open”
for analog valve
Y0p: control signal of stepper
control – opening
YCl: control signal of stepper
control – closing
Cool: control signal cooling
or control signal „close”
for analog valve
AHi: upper absolute alarm
Alo: lower absolute alarm
dwHi: upper relative alarm
dwlo: lower relative alarm
dwin: inner relative alarm
dwou: outer relative alarm
aLtr: timer alarm
aLhb: heater damage alarm
aLos: : controlling element
damage alarm
(short circuit)
retr: retransmission
eu1: auxiliary output for the
program-following control
eu2: auxiliary output for the
program-following control
aLfl: alarm in case of sensor
failure or exceeding the
measuring range
o#ty
Output type 2 4-20 2)
rely: relay output
ssr: voltage output 0/5 V
4-20: continuous current
output 4 – 20 mA
0-20: continuous current
output 0 – 20 mA
0-10: continuous voltage output
0 – 10 V
