Lumel RE72 User Manual

21
21
out3
Function of
output 3
off
off: without function
Y: control signal - heating
or control signal „open”
for analog valve
Y0p: control signal of stepper
control – opening
YCl: control signal of stepper
control – closing
Cool: control signal - cooling
or control signal „close”
for analog valve
AHi: absolute upper alarm
Alo: lower absolute alarm
dwHi: upper relative alarm
dwlo: lower relative alarm
dwin: inner relative alarm
dwou: outer relative alarm
aLtr: timer alarm
aLhb: heater damage alarm
aLos: controlling element
damage alarm
(short-circuit)
eu1: auxiliary output for the
program-following control
eu2: auxiliary output for the
program-following control
aLfl: alarm in case of sensor
failure or exceeding the
measuring range
fa1l
Selection of the
control signal
of the output
for proportional
control in case
of a sensor
failure or for
program con-
trol in case of
control stoppa-
ge
7)
off- the output is turned off
Yfl - the output takes the value
set with the Yflparameter
Mean - the output takes the
mean value. The maximum
allowable value of the control
signal at the output can be de-
fined with the YmH parameter.
The mean value is measured
at 1-minute intervals and only
when the system deviation is
lower than the Lym parameter
value
