Lumel RE72 User Manual

24
24
pid3 pb3
ti3
td3
y03
Third set of
PID para-
meters
as PB, TI, TD, Y0
pid4 pb4
ti4
td4
y04
Fourth set
of PID pa-
rameters
as PB, TI, TD, Y0
pidC
pbC Proportional band
for the cooling
channel (in relation
to PB)
100.0 % 0.1...200 %
tiC Integration time
constant
300 s 0...9999 s
tdC Differentiation
time constant
60.0 s 0.0...2500 s
alar – Alarm parameters
a1.sp
Set point value for abso-
lute alarm1
100.0 MIN...MAX 3)
a1.du
Deviation from the set
point value for relative
alarm 1
2.0
o
C
-200.0... 200.0
o
C
(-360.0... 360.0
o
F)
a1.Hy Hysteresis for alarm 1 1.0
o
C
0.2...100.0
o
C
(0.2...180.0
o
F)
a1.lt Memory of alarm 1
off
off: disabled
on: enabled
a#sp
Set point value for abso-
lute alarm 2
100.0 MIN...MAX 3)
a#du
Deviation from the set
point value for relative
alarm 2
2.0
o
C
-200.0... 200.0
o
C
(-360.0... 360.0
o
F)
a#Hy
Hysteresis for alarm 2 1.0
o
C
0,2...100,0
o
C
(0,2...180,0
o
F)
