Parameters depended on the measuring range Table 2
Symbol Input/ sensor MIN MAX
pt1
Resistance thermometer
Pt100
-200
O
C
(-328
O
F)
850
O
C
(1562
O
F)
pt10
Resistance thermometer
Pt1000
-200
O
C
(-328
O
F)
850
O
C
(1562
O
F)
t-,
Thermocouple of J type
-100
O
C
(-148
O
F)
1200
O
C
(2192
O
F)
t-t
Thermocouple of T type
-100
O
C
(-148
O
F)
400
O
C
(752
O
F)
t-k
Thermocouple of K type
-100
O
C
(-148
O
F)
1372
O
C
(2501,6
O
F)
t-s
Thermocouple of S type
0
O
C
(32
O
F)
1767
O
C
(3212,6
O
F)
t-r
Thermocouple of R type
0 °C
(32 °F)
1767
O
C
(3212,6
O
F)
t-b
Thermocouple of B type
0
O
C
(32
O
F)
1767
O
C
(3212,6
O
F)
t-e
Thermocouple of E type
-100
O
C
(-148
O
F)
1000
O
C
(1832
O
F)
t-n
Thermocouple of N type
-100
O
C
(-148
O
F)
1300
O
C
(2372
O
F)
t-l
Thermocouple of L type
-100
O
C
(-148
O
F)
800
O
C
(1472
O
F)
0-20
Linear current 0-20mA
-1999 1) 9999 1)
4-20
Linear current 4-20 mA
-1999 1) 9999 1)
0-10
Linear voltage 0-10 V
-1999 1) 9999 1)
1) The defi nition at which the given parameter is shown depends on
the parameter dp – position of the decimal point.
