4003 R- 0…0xFFFF
Controller status – description in
table 12
4004 R- 0…0xFFFF Alarm state – description in table 13
4005 R- 0…0xFFFF Error status – Description in table 14
4006 R- acc. to table17
1)
Measured value PV
4007 R- -1999…9999 Measured value on additional input
4008 R- acc. to table17
1)
Current set point value SP
4009 RW 0…1000 Control signal of loop 1 [% x10]
2)
4010 RW 0…1000 Control signal of loop 2 [% x10]
2)
4011 R- 0…59994 Timer value [s]
4012 R- 0…500
Heater current when the output is
turned on [A x10]
4013 R- 0…500
Heater current when the output is
turned off [A x10]
4014 UNIT RW 0…2
Unit
0 – Celsius degrees
1 – Fahrenheit degrees
2 – physical units
4015 INPT RW 0…14
Kind of main input:
0 – resistance thermometer Pt100
1 – resistance thermometer Pt1000
2 – thermocouple of J type
3 – thermocouple of T type
4 – thermocouple of K type
5 – thermocouple of S type
6 – thermocouple of R type
7 – thermocouple of B type
8 – thermocouple of E type
9 – thermocouple on N type
10 – thermocouple of L type
11 – current input: 0-20mA
12 – current input: 4-20mA
13 – voltage input: 0-5 V
14 – voltage input: 0-10 V
