Setting range of controller parameters:
See table 1
Binary input voltageless
- shorting resistance ≤ 10 kΩ
- opening out resistance ≥ 100 kΩ
Kinds of outputs 1 and 2:
- voltageless relay NOC contact, load capacity
2 A/230 V a.c.,
- voltage transistor 0/5 V, maximum load capacity:
40 mA
- continuous voltage 0…10 V at R
load
≥ 1 kΩ
- continuous current 0…20 mA, 4…20 mA at
R
load
≤ 500 Ω
Kinds of output 3:
- voltageless relay NOC contact, load capacity
1 A/230 V a.c
Way of output operation:
- reverse for heating
- direct for cooling
Error of analog outputs 0.2% of the range
Digital interface RS-485
- Modbus protocol
- baud rate 4800, 9600, 19200, 38400,
57600 bit/s
- mode RTU – 8N2, 8E1, 8O1, 8N1
