Lumel RE72 User Manual

90
90
- address 1…247
- maximum response time 500 ms
Supply of object transducers 24V d.c. ± 5 %, max.: 30 mA
Signaling:
- switching the output 1 on
- switching the output 2 on
- switching the output 3 on or switching the binary input on
- mode of manual control
- auto-tuning process
Rated operating conditions:
- supply voltage 85…253 V a.c./d.c.
20…40 V a.c./d.c.
- frequency 40…440 Hz
- ambient temperature 0…23…50 °C
- storage temperature -20…+70 °C
- relative air humidity < 85 % (condensation
inadmissible)
- preheating time 30 min
- operating position any
- resistance of wires connecting the
resistance thermometer or the
thermocouple with the controller < 20 Ω / wire
Power input < 8 VA
Weight < 0.2 kg
