14
4.10
Connecting to a computer with RS232
After con
necting to the RS232 cable, you can use RS232 comm
ands to
control PC193.
4.11
Connecting to a TV
NTSC: USA, Canada, Mexico, Panama,
Chile, Japan, T
aiwan, Korea, and
Philippines.
RS232 cable
Power cord
A
C outlet
Computer
EXTENDER
cable
DIP sw
itch setting
Power cord
AC outlet
C-Video Cable
EXTENDE
R
cable
14
16
