37
Chapter 9 DIP
switch setting
<Note> Y
ou should unplug and reconnect the power cord, and then
rest
art the PC193 for all DIP switch settings to t
ake effect.
9.1
Connecting to a projector or monit
or
9.1.1 XGA
output
9.1.2 SXGA
output
9.1.3 WXGA
output
37
39
