Luminex 200 User Manual

Luminex 200 System User Manual
24
Figure 5 Removing the Screen
3. Replace the filter and replace the screen. See Figure 6.
Figure 6 Removing and Replacing the Filter
4. Plug in and turn on Luminex XYP instrument power.
Syringe Seal To replace the syringe plunger seal:
1. Turn the power switch on the back of the analyzer to the off
position.
Warning: The syringe arm does not deactivate when changing the
plunger; injury could result if the system is not unplugged.

Luminex 200 Specifications

General

Power Requirements	100-240 VAC, 50/60 Hz
Dynamic Range	3.5 logs
Number of Analytes	Up to 100
Software	xPONENT
Application	Immunoassays, Nucleic Acid Detection, Enzyme Assays
Technology	xMAP (Multi-Analyte Profiling)
Bead Types	Color-coded microspheres
Lasers	2 (532 nm and 635 nm)
Assay Types	Immunoassays, nucleic acid assays, enzyme assays
Sample Volume	12.5 - 50 µL
PMT Detectors	Yes
