Luminex GigaCore Series User Manual

40
Luminex LCE operates a policy of continuous development. Luminex LCE reserves the right to make changes and
improvements to any of the products described in this document above without prior notice. Specications are subject
to change without notice.
Management
■ Conguration
■ Through the built-in web server ■ Through the built-in web server ■ Through the built-in web server or
with the front end display menu
■ Through the built-in web server or
with the front end display menu
■ GigaCore 12 ■ GigaCore 14R ■ GigaCore 16Xt ■ GigaCore 16RFO
Power Input
■ Power Input
■ 100-240VAC
■ 50-60Hz
■ 100-240VAC
■ 50-60Hz
■ 100-240VAC
■ 50-60Hz
■ 100-240VAC
■ 50-60Hz
■ Backup Power Input
■■ O
■ 15VDC / 2A on Molex Micro-Fit
■ 6 pin connector
■ 15VDC / 2A on Molex Micro-Fit
■ 6 pin connector
■ 100 - 240VAC on Neutrik PowerCon
True1 connector
■ Backup PoE Input
■■ O
■ 48VDC / 2.1A on Molex Micro-Fit
■ 6 pin connector
■ 48VDC / 2.1A on Molex Micro-Fit
■ 6 pin connector
■ 100 - 240VAC on Neutrik PowerCon
True1 connector
■ Power Consumption
■ Maximum 30W
■ Maximum 180W with PoE Supply
Unit
■ Maximum 30W
■ Maximum 180W with PoE Supply
Unit
■ Maximum 30W
■ Maximum 180W with PoE Supply
Unit
■ Maximum 30W
■ Maximum 180W with PoE Supply
Unit
■ Fuse
■ 3.15A 250V Slow Blow ■ 3.15A 250V Slow Blow ■ 3.15A 250V Slow Blow
■■ O
Environmental
■ Operating Temperature
■ 0 to +50 °C ■ 0 to +50 °C ■ 0 to +50 °C ■ 0 to +50 °C
■ Storage Temperature
■ -10 to +70 °C ■ -10 to +70 °C ■ -10 to +70 °C ■ -10 to +70 °C
■ Humidity (non condensing)
■ 5 to 95 % RH ■ 5 to 95 % RH ■ 5 to 95 % RH ■ 5 to 95 % RH
Physical
■ Enclosure
■ Metal housing ■ Metal housing ■ Metal housing ■ Metal housing
■ Dimensions (W x D x H)
■ 482 x 204,3 x 44 mm
■ 19” x 8.04” x 1.73”
■ 482 x 204,3 x 44 mm
■ 19” x 8.04” x 1.73”
■ 482 x 204,3 x 44 mm
■ 19” x 8.04” x 1.73”
■ 482 x 294.15 x 88.45 mm
■ 19” x 11.58” x 3.48”
■ Packaging
■ 520 x 235 x 50 mm
■ 20.47” x 9..25” x 1.96”
■ 520 x 235 x 50 mm
■ 20.47” x 9..25” x 1.96”
■ 520 x 235 x 50 mm
■ 20.47” x 9..25” x 1.96”
■ 510 x 410 x 136 mm
■ 20.07” x 16.14” x 5.35”
■ Weight
■ 2.5Kg ■ 2.5Kg ■ 2.5Kg ■ 4.9Kg
Approvals
■ CE
■■  ■■  ■■  ■■ 
■ EN 55103-1
■■  ■■  ■■  ■■ 
■ EN 55103-2
■■  ■■  ■■  ■■ 
■ EN 60950-1
■■  ■■  ■■  ■■ 
■ RoHS Compliance
■■  ■■  ■■  ■■ 
Sheet 2/2

Luminex GigaCore Series Specifications

General

PoE	Available on select models (PoE, PoE+, PoE++)
Management	CLI
VLAN	Yes
Cooling	Fanless or with fans (depending on model)
Mounting	Rack-mountable (depending on the model)
Dimensions	Varies by model (see individual datasheets)
Operating Temperature	0°C
Storage Temperature	-20°C to 70°C
Model	GigaCore Series
