Lust SMARTDRIVE VF1205M - Parameter Configuration; Parameter List Overview

5-1
5 Parameter list
5.1 Operating level 1
Abbrev. Name Unit Display range Page Factory Customer
setting
Actual values
10-G Scaled frequency - 0 to 65535 6-5
12-F Output frequency Hz 0.0 to 999.0 6-5
13-U Output voltage V 0 to 460 6-6
14-IS Apparent current A 0.0 to 52.0 6-6
15-IW Effective current A 0.0 to 52.0 6-6
16-PW Effective power W 0 to 22000 6-6
17-UZK DC-link voltage VDC 0 to 900 6-6
18-TIME Switch-on dura. from reset h 0.0 to 960.0 6-6
19-TOP Operating hours h 0 to 60000 6-6
Device data
91-TYPE Inverter type - 15 types possible 6-21
92-REV Software version - - 6-21 see 2nd cover page
95-ERR1 Last error - 0-0.0 to 9-1.5 6-22
11-0.0 to 11 -1.5
Abbrev. Name Unit Setting range Page Factory Customer
setting
1-MODE Operating mode - 0 to 3 6-1 1
Frequencies
20-FF2-1 Fixed frequency 2 Hz 0.0 to 999.0 6-7 3
21-FMIN1 Minimum frequency Hz 0.0 to 999.0 6-7 0
22-FMAX1 Maximum frequency Hz 4.0 to 999.0 6-7 50
23-FF3 Fixed frequency 3 Hz 0.0 to 999.0 6-7 15
24-FF4 Fixed frequency 4 Hz 0.0 to 999.0 6-7 30
25-FF5 Comparative freq. S2OUT Hz 0.0 to 999.0 6-7 3
Ramps
32-RACC1 Acceleration ramp 1 Hz/s 0.1 to 999.0 6-9 20
33-RDEC1 Delay ramp 1 Hz/s 0.1 to 999.0 6-9 20
36-RSTOP STOP-delay ramp Hz/s 0.0 to 999.0 6-9 0
Characteristics
41-V/FC V/F characteristics selector - 1 and 4 6-10 1
42-VB1 Start voltage (Boost 1) % 0.0 to 25.0 6-10 8
43-FN1 Frequency rated point Hz 15.0 to 960.0 6-10 50/60**
44-VN1 Voltage rated point V 43%...119% U
Rated
6-10 *
*Dependent on inverter type, **Factory setting B
