Table of Contents
Luxor
®
Overview
3 Luxor Components
4 Glossary of Terms
4 Safety Information
Installing the Luxor Transformer
5 Step 1 – Location Selection
5 Step 2 – Mounting Transformer
6 Step 3 – Running Cable to the Fixtures
Cabling Methods 8
Connecting Cables at the Terminal Block 8
Operating the Luxor
9 Navigating the Luxor
9 HOME Screen
9 ACTIVITY Screen
10 DIAGNOSTICS Screen
11 Setup Screen
Time/Date 11
Language 12
Location 12
Assign 13
Network 13
Restrict 13
Backup 14
Contact Card 14
15 Assigning Light Fixtures into Groups
16 Setting up Programs
16 Themes
17 Manual Mode
18 Color
Color Palette 18
Incorporating Color into Luxor 19
Mixing FX LED, ZD, and ZDC 21
22 Using Other Devices with the Luxor
23 Shutdown
24 Luxor Linking System Setup
Care and Maintenance
27 Regular Preventive Maintenance
28 Troubleshooting
29 Firmware Updates
30 Fuse Replacement
30 System Reset
Facepack Reset 32
Database Reset 32
33 Chassis Indicator Lights
34 Warranty
