Luxor ZD - Troubleshooting

28
Care and Maintenance
Troubleshooting
Problem Cause Resolution
Error Message: "Overload"
(Uppercase "O")
An uppercase “O” overload indicates current far in
excess of normal operating current, typically caused by
a short circuit. This is controlled by a hardware circuit
and trips the overload immediately.
Check for shorts in the line. Resolve or
repair the short circuit.
Error Message: “overload”
(Lowercase “o”)
A lowercase “o” overload indicates a current in excess
of the rated current, but not as much as the uppercase
“O”. For 150w transformers the limit is 11 Amps, and
for 300w transformers the limit is 22 Amps. For this
current to trip the overload, it must be continually
above these values for 1 second.
Reduce the number of xtures by one,
turning on, and repeating until the
“overload” does not occur. Resolve/
repair the short circuit.
Error Message: “No Wi–Fi Card
Present.”
Wi–Fi card not detected. Pull out the Wi–Fi Card and re-insert.
If problem persists, replace with a new
Wi–Fi card.
Error Message: “Communications
Failure.”
Communication between the facepack and chassis is
not present.
Replace the cable connecting the
facepack to the chassis. If problem
persists, call technical services.
Transformer will not turn o when
program is complete.
No o time programmed. Go to programs and add an event
time with an intensity of zero for your
o time.
The transformer’s display is on, but
no xtures are on.
The transformer’s fuse has blown. Replace fuse in transformer.
NOTE: Shorts and overloads are NOT covered by the FX warranty and can be detected only when the transformer is tested in the eld.
Periodic system maintenance is required to keep your FX lighting system operating at peak performance. Practicing these maintenance
suggestions will lengthen the life and enjoyment of your lighting design.
