Colibri Manual Ver. 4.2 Dec 2006
LX Navigation d.o.o. www.lxnavigation.si
10
After approximately one second the display will change to the first navigation page, where the first 4 characters
of the name and basic navigation data will be displayed (t…track, b….bearing, k/m…. distance).
Pressing Esc will change to a second navigation page in which the ground speed replaces the name of the TP.
kh…… Grund speed
A further press of Esc will display the wind calculation.
The wind calculation is based on measuring drift while climbing in a thermal. Two full circles are necessary
before the wind can be displayed. The procedure is fully automatic and requires no pilot manipulation other
than to try and keep the speed constant while thermalling.
Note!
To scroll through the stored TPs use the vertical arrows ▲▼. The longer the press, the faster the scrolling.
The TPs are always sorted alphabetically.
3.2.2.2 Editing TP data and the input of new data
Pressing Enter when the TP mode is selected will open the following menu. Use the vertical arrow keys ▲▼
to scroll through the following options.
123°t CUND
126°b235km
123° t 134 kh
126° b 235km
Wind
234 ° 24 kh
TP
MENU
NEW
POINT
EDIT
TPOINT
DELETE
TPOINT
EDIT
TASK
