6.2 Connecting Flarm to NANO
3
6.3 Connecting Flarm to NANO
3
using NanoPower-FL
6.4 Connecting Flarm to NANO
3
using NanoPower-PF
Nano Power
Must be connected to 12V
USB cable
CC-NP-IGC
cable
NANO
3
NanoPower-FL
gets 12V from flarm
USB cable
NANO
3
Flarm
NanoPower-PF
gets 12V from flarm
USB cable
NANO
3
PowerFlarm
Needs separate 12V supply
Flarm
