15
Code 49
Top Panel
F6 F7 F8 F9
1
23
46
5
Important: For more complete explanations of how to use all of these controls, please see the
Operation chapter.
1. Keyboard: This 49-note keyboard is velocity-sensitive with aftertouch and, in conjunction
with the Key Octave –/+ buttons, can access the full range of 127 available MIDI notes (10
octaves).
2. Pitch-Bend Wheel: Move this wheel to send MIDI pitch bend information.
You can also change this wheel’s MIDI assignment. See Operation > Wheels > Editing
Assigments to learn how to do this.
3. Modulation Wheel: Move this wheel to send continuous controller data—MIDI CC 01
(modulation), by default.
You can also change this wheel’s MIDI assignment. See Operation > Wheels > Editing
Assigments to learn how to do this.
4. Key Octave –/+: Press one of these buttons to move the keyboard up or down an octave.
Press and hold Transpose and press one of the buttons to move the keyboard down or
up a semitone.
5. Pads: Use these pads to trigger drum hits or other samples in your software or external
MIDI sound module. The pads are velocity-sensitive, which makes them very responsive
and intuitive to play.
You can also change these pads’ MIDI assignments. See Operation > Pads > Editing
Assigments to learn how to do this.
6. Pad Octave –/+: Press one of these buttons to move the pads up or down an octave.
Press and hold Transpose and press one of the buttons to move the pads down or up a
semitone.
