66
Messages
MIDI CCs
You can assign an axis of the X-Y pad to send a MIDI CC message when you move your finger
along it.
The X-Y pad must be in MIDI Mode to do this (see Modes > MIDI Mode).
To assign a MIDI CC to an axis of the X-Y pad:
1. Press Edit to enter Edit Mode. The Edit button will light up.
2. Press the X or Y button. X or Y will appear in the display.
3. Press the Ctrl Assign key. The display will show ASGN for 1 second and then show X or
Y and a number for the type of message it sends.
4. Use the numeric keys (0–9) or Preset Down/Up () buttons to enter a MIDI CC number
(001–127).
5. Press the Data 2 key. The display will show DATA2 for 1 second and then show X or Y
and the value it will send at its minimum position.
6. Use the numeric keys (0–9) or Preset Down/Up () buttons to enter a value (001–127).
7. Press the Data 3 key. The display will show DATA3 for 1 second and then show X or
Y
and the value it will send at its maximum position.
8. Use the numeric keys (0–9) or Preset Down/Up () buttons to enter a value (001–127).
9. Press the Enter key. The axis is now set to send the assigned MIDI CC, and you will exit
Edit Mode.
To cancel your changes instead, press Edit. You will exit Edit Mode without saving anything.
Remember to store the preset if you want to save your changes in that preset.
Tip: You can reverse the direction (polarity) of the axis so that moving your finger in the
positive direction decreases the value and moving it in the negative direction increases it.
To do this, enter the desired maximum value in Step 5 and the desired minimum value in
Step 7.
