Warning: The cable screen must be connected to the weight of the machine.
Do not connect the screen to any clamp of SmartControl. The screen must be
insulated so as not to touch the adapter plate in SmartControl. Failure to secure
the screen may damage SmartControl.
It is recommended to use the ready-made cable LiYCY-P 12 x 2 x 0.14 mm ²
(available under catalog numbers SC5-CAB-N-AAA, SC5-CAB-S-AAA, SC5-
CAB-D-AAA-BBB), but it is also possible to connect another cable with the
following parameters: AWG26 - AWG24 0.14 mm ² - 0.5 mm ² and a maximum
Warning: Please check carefully the correct wiring. 24V connection to one of
the communication clamps (3 - 9) will cause irreparable damage to
SmartControl.
Warning: Do not connect any voltage higher than 24VDC to clamps 10-17 of
Emergency off switch / Emergency Stop and Approval Key.
Connecting a higher voltage may result in electric shock and / or damage to
SmartControl.
Warning: Connections can only be performed by a person with appropriate
qualifications.
