SPECIFICATIONS
Form 169304 15 Model Year - 2009
Type
Hydraulic
Gear Pump
Displacement 1.02 cu.in. (16.7 cc)
Flow 11.5 U.S. gpm (46.5 L/min)
System Pressure (Relief/Max)
2500 psi (17.24 MPa)
Header Tilt
Mechanically Adjustable Link (Optional Hydraulic Cylinder Adjustable From
Cab)
Adjustable Springs
Manual, External, Draw-Bolt With Springs (1 per side)
Dimensions
Width
63 in. (1600 mm)
Depth
68.3 in. (1735 mm) (at top of window)
Height
64.6 in. (1640 mm)
Volume
125 cu.ft. (3540 liters)
Seat
Driver
Mechanical Suspension, Seat Belt
Folding, Cab Mounted, Seat Belt
Windshield Wiper
Front
31.5 in. (800 mm) Blade
Heater
24,000 Btu/h (7038 W)
Air Conditioning
28,280 Btu/h (8288 W)
Electrical Outlets
One Live, One On Ignition, One Live/Keyed.
Mirrors
Two Outside
Radio
Two Speakers and Antenna Factory Installed.
Dealer Installed Radio
Speeds
Ground (mph or km/h), Engine (rpm), Knife (spm) Optional, Reel (rpm)
Optional, Conveyor (Ref. No.)
Header Height, Angle (Optional)
Size
Drive
18.4 – 26 Bar, 18.4 – 26 Turf
Rear
7.5 – 16SL Single Rib Formed Caster, 10 x 16 Formed/Forked Caster
16.5L – 16.1 Rib Implement Flotation, Forked Caster
Pressure
Drive
Bar – 32 psi (221 kPa), Turf – 20 psi (138 kPa)
Rear
10 psi (69 kPa)
Dimensions
Refer to Section 4.1, Windrower Tractor Dimensions
Frame to Ground (Crop Clearance)
45.7 in. (1160 mm)
Weight
Approx. 9900 lb (4491 kg)
NG Header Compatibility
SK
A30S Auger, D50 & D60S Harvest Header (35’ Max.)
DK
A30D, A40D Auger, D60D Harvest Header (35’ Max.)
NOTES: 1. Specifications and design are subject to change without notice or obligation to revise previously
sold units.
2. Weights do not include options.
