MacDon M100 2009 - Header Functions

OPERATOR’S STATION
Form # 169304 46 Model Year - 2009
Windrower Tractor Operating
Symbols
(cont’d)
Air Conditioning Fresh Air
Blower
6.2.3 Header Functions
Program
Header Tilt
Up
Header Index
Header
Down
Return To Cut Header Up
Conveyor
Speed
Header Tilt
Down
Increase
Decrease
Reel Speed Deck Shift
Reel Down
Header
Engage
Reel Forward
Header
Disengage
Reel Up
Push Down
Header
Disengage
Reel Rearward
Pull Up
Header
Engage
Display Select
