MacDon M100 2009 - 4.2 SPECIFICATIONS

SPECIFICATIONS
Form # 169304 14 Model Year - 2009
4.2 SPECIFICATIONS
ENGINE
Type Cummins QSB-3.3 4 Cyl. Turbo
Displacement 200 cu. in. (3.3liters)
Power
Rated
99 hp (74 kW) @ 2600 rpm
Peak
99 hp (74 kW) @ 2000 rpm
Maximum RPM (no load) 2630-2650
Idle RPM 1100
ELECTRICAL SYSTEM
Recommended Battery
12 Volt, Min. 950CCA, Max Dim – 12.5x7x10 in. (317x178x254 mm).
Group Rating 31A. Heavy Duty/Off Road/Vibration Resistant.
Alternator 120 amp
Starter Dry Type
Working Lights 11
TRACTION DRIVE
Type Hydrostatic, 2 Speed Electric Shift
Speed
Field
Lo Range 0-11 mph (17.7 km/h)
Reverse
6 mph (9.6 km/h)
Transport
High Range 0-16 mph (25.6 km/h)
Transmission
Type
2 Piston Pumps – 1 per Drive Wheel.
Displacement
3.0 cu.in. (49 cc)
Flow
33 U.S. gpm (129 L/min)
Final Drive
Type
Planetary Gearbox
Ratio
41.42 : 1
Wheel Motor Displ.
Lo Range
2.8 cu.in. (46 cc)
Hi Range
1.7 cu.in. (27 cc)
SYSTEM CAPACITIES
Fuel Tank
97 U.S. Gallons (378 liters)
Cooling
5.1 U.S. Gallons (20 liters)
Hydraulic Reservoir
11.5 U.S. Gallons (45 liters)
Crankcase
1.9 U.S. Gallons (7 liters)
HEADER DRIVE
Type Displacement Flow Max. Press.
Knife Drive – Pump A (Mechanically Adjustable) Piston
3.0 cu.in.
(0-49 cc)
0-30 U.S. gpm (117
L/min)
4000 psi
(27579 kPa)
Reel Drive – Pump B
Gear
1.02 cu.in.
(16.7 cc)
0-
11.5 U.S. gpm (45
L/min) @ 2600 rpm
2600 psi
(17926 kPa)
Conveyor – Pump C
(continued next page)
