MAINTENANCE/SERVICE
Form 169304 97 Model Year - 2009
7.6.2 Lubrication Points
Refer to the illustrations on the following page
for identifying the various locations that require
lubrication.
TOP LINK – TWO FITTINGS
(BOTH SIDES)
CASTER PIVOT
(BOTH SIDES)
High Temp. Extreme Pressure
(EP2) Performance With 1%
Max Molybdenum Disulphide
(NLGI Grade 2).Lithium Base
FORKED CASTER SPINDLE BEARINGS
TWO PLACES (BOTH WHEELS)
FORMED CASTER WHEEL BEARING
1 PLACE (BOTH WHEELS)
To Next Page
