MacDon M100 2009 - 7 MAINTENANCE;SERVICE (continued); 7.3 MAINTENANCE SPECIFICATIONS

MAINTENANCE/SERVICE
Form # 169304 90 Model Year - 2009
7.3 MAINTENANCE SPECIFICATIONS
7.3.1 Recommended Fluids, Fuel, and
Lubricants
7.3.1.1 Fuel
FUEL
SPEC
SULPHUR
(by weight)
WATER &
SEDIMENT
(by weight)
CETANE
NO.
LUBRI
CITY
Diesel
Grade
No.2
ASTM
D-975
As Per
Spec
As Per
Spec
As Per
Spec
As Per
Spec
Diesel
Grade
No.1 &
2 mix *
n/a
1% Max.
0.5% Max.
Preferred
0.1% Max.
45-55
Cold
Weather/
High Alt.
460
HFRR
* Optional when operating temp below 0˚C.
(32˚F.).
In extreme situations, when available fuels are
of poor quality or problems exist which are
peculiar to certain operations, additives can be
used. However, the engine manufacturer
recommends consultation with the fuel supplier
or engine manufacturer prior to use of fuel
additives. Among the situations where additives
can prove useful are the following:
• A cetane improver additive can be used with
low cetane fuels.
• A wax crystal modifier can help with fuels
with high cold filter plugging points (CFPP).
• An anti-icer can help prevent ice formation in
wet fuel during cold weather.
• An anti-oxidant or storage stability additive
can help with fuel system deposits and poor
storage stability.
• A lubricity enhancer can be used to increase
the lubricity of fuels so that they meet the
requirements given in the table on the
previous page.
Diesel fuel conditioner is available from your
dealer.
7.3.1.2 Fluids
FLUID
SPEC
DESCRIPTION
USE
Anti-Freeze
ASTM
D-4985
Ethylene Glycol
With SCA
Engine
Coolant *
Air
Conditioning
Refrigerant
R134A Refrigerant
Cab Air
Conditioning
System.
Compressor
Oil
SP-15 Compressor Oil
Cab Air
Conditioning
Compressor
Lubricant
* Mix with equal parts of high quality, soft, de-ionized, or distilled
water.
7.3.1.3 Lubricants
LUBRICANT
SPEC/DESCRIPTION
USE
Grease
SAE Multi-Purpose.
High Temp. Extreme
Pressure (EP2) Performance
With 1% Max Molybdenum
Disulphide (NLGI Grade 2).
Lithium Base
As Required
Unless
Otherwise
Specified.
Engine Oil
SAE 15W40 Compliant With
SAE Specs For API Class SJ
And CH-4 Engine Oil.
Engine
Crankcase
Hydraulic Oil
SAE 15W40 Compliant With
SAE Specs For API Class SJ
And CH-4 Engine Oil
Windrower
Drive.
Header
Drive.
Gear Lubricant
SAE 85W-140
API Service Class GL-5.
Extreme Pressure Gear
Lubricant
Drive Wheel
Gears
Before Initial
Change.
SAE 75W-90
API Service Class GL-5.
Fully Synthetic Gear
Lubricant
(SAE J2360 Preferred)
Drive Wheel
Gears After
Initial
Change.
7.3.1.4 Capacities
ITEM CAPACITY
Fuel Tank 97 U.S. Gallons (378 litres)
Hydraulic Reservoir
11.5 U.S. Gallons (45 litres)
Drive Wheel 1.5 U.S. Quarts (1.4 litres)
Engine Cooling System 5.3 U.S. Gallons (20 litres)
Engine Crankcase 7.6 U.S. Quarts (7 litres)
Air Cond. Refrigerant 3.6 lb (1.63 kg)
Air Cond. Compressor 8.1 fl. oz. (240 cc)
7.3.1.5 Storage
Your machine can operate at top efficiency only
if clean fuel and lubricants are used.
• Use clean containers to handle all fuels and
lubricants.
• Store in an area protected from dust,
moisture, and other contaminants.
• Buy good quality, clean fuel from a reputable
dealer.
• Avoid storing fuel over long periods of time.
If you have a slow turnover of fuel in
windrower tractor tank or supply tank, add
fuel conditioner to avoid condensation
problems.
• Store fuel in a convenient place away from
buildings.
