MacDon M100 2009 - 5 OPERATOR’S STATION (continued); 5.7 LIGHTS

OPERATOR’S STATION
Form 169304 19 Model Year - 2009
5.7 LIGHTS
The field and transport light switches are located
on a panel in the cab headliner. Refer to
illustrations on following pages for location of
lights.
5.7.1 Field Lighting
HI/LO LIGHTS
Controls Hi/Lo Beam For
Road Lights On Cab Roof
LIGHTS SWITCH
Controls Field and Transport Lights
FIELD
OFF
ROAD
BEACON
Controls Beacons On Cab.
Standard for Export. Optional for N.A.
On – Off
REAR
FIELD LIGHTS
SWATH LIGHTS
FRONT
FIELD LIGHTS
