MAINTENANCE WORK
TILTING DRIVER'S CAB
46 Maintenance manual T225/T230
Fig. 14: Hexagon head screws for fixating the cabin
1 Hexagon head screws
X Park the MT on level ground.
X Apply the parking brake.
X Put the transmission into neutral.
X Switch off the engine.
X Remove all loose objects from the driver's cab.
X Take the pump level out of the driver's cab.
X Loosen and remove the hexagon head screw 1.
Fig. 15: Hand pump, driver's cab
1 Closure
2 Valve lever
3 Pump lever
