MAINTENANCE WORK
TILTING DRIVER'S CAB
Maintenance manual T225/T230 47
Fig. 16: Valve lever positions
1 DOWN
2 UP
X
Insert the pump lever into the opening 1.
X Turn the valve lever 2 to the “UP” position.
X Pump with the pump lever.
3 The driver's cab is tilted.
X Pump until you no longer feel any counter-pressure. After
this, the driver's cab tilts forward on its own into the final
position.
The driver's cab is secured in this final position and cannot
tilt back onto the maintenance area for the motor.
Fig. 17: Tilted driver's cab in the final position
X
Wait until the driver's cab is secure in the final position; only
then can you begin with the maintenance work on the motor.
