MAINTENANCE WORK
DRIVE TRAIN
Maintenance manual T225/T230 67
Checking the level of the transmission oil with the oil
dip stick
CAUTION!
Transmission damage!
If the oil level is too high or too low, this can result in
damage to the transmission.
X Make sure that the oil level never exceeds the “HOT-
FULL” or drops below the “HOT-ADD” marking of the
oil dip stick when the oil is at operating temperature.
X Use only authorised types of transmission oil.
The level of the transmission has to be checked with the oil dip
stick in three steps after the initial operation or during the oil
change:
z Conduct an oil level check just before the motor is started
the first time after the commissioning or the oil change to
make sure that the filled in amount of oil is sufficient for the
cold check.
z Conduct a cold check after the first motor start and cold
transmission oil to make sure that the amount of oil is
enough for a reliable operation until the hot check.
z Conduct a hot check when the transmission oil is at
operating temperature to make sure that the amount of oil
is sufficient for normal operation.
During the daily oil level check, either conduct a hot
check or read the “Oil level mode” display in the
transmission operating panel.
The transmission oil has to be at operating temperature
for an exact oil level check.
The oil dip stick is located on the right side of the transmission.
