5 Wb magnetic flux in Weber for all coils
8 T magnetic flux density in Tesla for field coil
10 G magnetic flux density in Gauss for field coil
13 A/m magnetic field strength in Ampere pro Meter for Field Coil
16 Oe magnetic field strength in Oersted for Field Coil
18 A magnetic potential in Ampere for Potential Coil
21 Vs/n magnetic flux per turn for Surrounding Coil
22 Wb/n magnetic flux per turn for Surrounding Coil
23 Mx/n magnetic flux per turn for Surrounding Coil
24 Mx magnetic flux in Maxwell for coils
25 Vsm magnetic dipole moment for Moment Coil
26 Am² magnetic moment for Moment Coil
27 Gb magnetic potential in Gilbert for Potential Coil
Answer: UNIT x (x = 0...27)
The settings for other than the listed parameters values are not defined.
If a parameter that is not valid for the selected coil is sent, then the EF 14
switches to Vs.
RANGE Write: #RANGE x Measuring range: x = -4, -5, -6, -7 (for the ranges
10
-4
to 10
-7
Vs)
Answer: RANGE x x = -4, -5, -6, -7
Read: ?RANGE
Answer: RANGE x x = -4, -5, -6, -7
VAR Var. function
Write: #VAR 0 disable function
#VAR *x multiply the measured value by x
#VAR /x divide the measured value by x
Answer: VAR NONE function disabled
VAR *x the measured value is multiplied by x
VAR /x the measured value is divided by x
Read: ?VAR
Answer: the same as for Write.
MEM Request data from the measured data memory, parameter x: number of the
memory cell
Read: ?MEM x
Answer: Value of the memory content, if the memory cell is occupied,
otherwise “void”.
6.3.4 Limit Commands
