7.3 Multi-functional Socket
Table 7.3.1: Assignments of the 25-pole Sub-D socket
Pin Function
1
Low limit relay, normally open
2
Low limit relay, center contact
3
Low limit relay, normally
closed
4
High limit relay, normally open
5
High limit relay, center contact
6
High limit relay, normally closed
7
Digital ground
8
Reserved, do not connect!
9
Digital Input/Output, reserved for future use
10
Digital ground
11
Digital ground
12
Digital ground
13
Digital output, ready for measurement
14
Auxiliary analog output, AC RMS
15
Analog ground
16
Auxiliary analog output,
±5 V
17
Analog ground
18
Analog output,
±1 V
19
Digital ground
20
Digital ground
21
Digital ground
22
Digital
input, Drift
23
Digital input, Reset
24
Digital input, Hold
25
No connection
