5 Programming
22 MAGNETEK HPV1000 AC Elevator Drive Technical Manual
Ser2 Fault Mode
Defines how the drive will react if serial communication is
lost (when using serial mode 2 only).
Immediate - the lift will crash stop immediately.
Rescue - the lift will continue at SER2 Res Crp Spd until
either the enable signal is removed or Ser2 ResCrpTime
elapses.
Run Remove - the drive will behave in the same way as if a
run command is removed as defined by other sequencing
parameters (stopping mode, etc.).
– Immediate
– Rescue
– Run Remove
Rescue
Trq Comp Cmd Src
<3>, <4>
Selects the source for the Torque Compensation Command if
used.
– Analog
– Serial HPV
– Option Card
Analo
<3>, <4>
Trq Comp Latch <3>, <4>
If Torque Compensation is used, this parameter selects
whether the values is latched on run command.
– Disabled
– Enabled
Disabled
<3>, <4>
Trq Comp Type <3>, <4> Selects which Torque Compensation method is used
– Pre-torque
– Feed Forward
Pre-torque
<3>, <4>
Mtr Overload Act
Determines which action the drive takes when a Motor
Overload has been detected.
– Alarm Only
– Fault
Alarm Only
Field Force Sel
<2>, <3> Determines if Field Forcing is in operation
– Disabled
– Enabled
Disabled
<2>, <3>
Restart Sel
Determines if the fault output is active when a reset is
attempted
– Flt Outp Disabld
– Flt Outp Enabled
Flt Outp Disabld
Out Ph Loss Det Defines the output (motor) phase loss detection method
– Disabled
– 1PH Loss Det
– 2/3PH Loss
– DC-PH
DC-PH
DB Tr Protection
Defines if the internal DBR protection is active (can be
disabled when using a regen unit or external brake module)
– Enabled
– Disabled
Enabled
Autotune Cont On
Determines the state of the motor contactor output during
Auto-Tuning.
– Disabled
– Enabled
– Enable at HBB
Disabled
Power Supply Sel Selects the backup power supply method.
– Battery
– Single Phase UPS
– Three Phase UPS
Single Phase UPS
Auto Fc Reduce
If enabled, Torque Boost increases the output current limit
while decreasing the carrier frequency when required
Disabled
Enabled
Disabled
OH Pre-Alarm Sel Defines the operation in the event of an overheat alarm.
Alarm Only
Ramp to Stop
Coast to Stop
Alarm Only
Inp Ph Loss Det Defines when the drive should declare a PF Fault.
En During Run
Disabled
En at Const Spd
Disabled
PPT Select
When enabled the drive will sense cabin load prior to lifting
brake outputs, then pretorque motor to prevent rollback.
Disabled
Enabled
Disabled
Mains Dip Enable
When enabled, this allows the maximum operating speed to
be limited under low mains voltage or when commanded via a
logic input
Disabled
External TB
Low Mains
Disabled
Output V Lim Sel
<2>, <3>, <4>
Function that will automatically decrease motor flux when the
output voltage reaches the saturation range.
-Enabled,
-Disabled <2>, <3>, <4>
Enabled <2>, <3>
Fan Selection Used to determine how the drive cooling fans will operate.
– Run With Timer
– Run Always
– Temp Controlled
Run With Timer
Inspection PWM
Sets if the drive will run at reduced PWM frequency when on
inspection control.
– 2kHz
– Default Carrier
2kHz
Rescue PWM
Sets if the drive will run at reduced PWM frequency when in
rescue operation.
– 2kHz
– Default Carrier
2kHz
<2> Parameter accessible in Open Loop Vector control mode
<3> Parameter accessible in Closed Loop Vector control mode
<4> Parameter accessible in PM Closed Loop Vector control mode
<5> Default is dependent on drive model number
C1 Parameter Name Description
Choices Default
