5 Programming
MAGNETEK HPV1000 AC Elevator Drive Technical Manual 23
Table 7 Logic Inputs C2 Submenu
Table 8 Logic Input Choices
C2 Parameter Name Description
Default
Logic Input S1 Logic Input 1 on terminal S1 Not Used
Logic Input S2 Logic Input 2 on terminal S2 Not Used
Logic Input S3 Logic Input 3 on terminal S3 Not Used
Logic Input S4 Logic Input 4 on terminal S4 Not Used
Logic Input S5 Logic Input 5 on terminal S5 Not Used
Logic Input S6 Logic Input 6 on terminal S6 Not Used
Logic Input S7 Logic Input 7 on terminal S7 Not Used
Logic Input S8 Logic Input 8 on terminal S8 Not Used
C2 Parameter
Choice
Description
Brake Feedback NC Brake Feedback Normally Closed
Brake Feedback NO Brake Feedback Normally Open
Comm Test Mode Serial Comm Test Mode
Contact Cnfm NC Contactor Confirmation Normally Closed
Contact Cnfm NO Contactor Confirmation Normally Open
DL Dist Correctn Stop Distance Correction Input
Drive Enable Drive Enable
BaseBlock NC Base Block Normally Closed
BaseBlock NO Base Block Normally Closed
Fast-Stop NO Fast Stop Normally Open
Fast-Stop NC Fast Stop Normally Closed
Fault Reset Fault Reset
Insp Operation Inspection Operation
Intermed Speed Intermediate Speed
Jog Freq Ref Jog Frequency Reference
Leveling Speed Leveling Speed
Mains Dip Enable Mains Dip Enable
Multi-Step Ref 1 Multi-Step input 1
Multi-Step Ref 2 Multi-Step input 2
Multi-Step Ref 3 Multi-Step input 3
Multi-Step Ref 4 Multi-Step input 4
NC Ext Fault 1
Normally Closed External Fault (always detect,
ramp to stop)
NC Ext Fault 2
Normally Closed External Fault (always detect,
cost to stop)
NC Ext Fault 3
Normally Closed External Fault (always detect,
fast stop)
NC Ext Fault 4
Normally Closed External Fault (always detect,
alarm only)
NC Ext Fault 5
Normally Closed External Fault (during run,
ramp to stop)
NC Ext Fault 6
Normally Closed External Fault (during run,
cost to stop)
NC Ext Fault 7
Normally Closed External Fault (during run, fast
stop)
NC Ext Fault 8
Normally Closed External Fault (during run,
alarm only)
NO Ext Fault 1
Normally Open External Fault (always detect,
ramp to stop)
NO Ext Fault 2
Normally Open External Fault (always detect,
cost to stop)
NO Ext Fault 3
Normally Open External Fault (always detect,
fast stop)
NO Ext Fault 4
Normally Open External Fault (always detect,
alarm only)
NO Ext Fault 5
Normally Open External Fault (during run, ramp
to stop)
NO Ext Fault 6
Normally Open External Fault (during run, cost
to stop)
NO Ext Fault 7
Normally Open External Fault (during run, fast
stop)
NO Ext Fault 8
Normally Open External Fault (during run,
alarm only)
Nominal Speed Nominal Speed Input
Not Used Input Not Used
Pre-Torque Latch Pre-Torque Latch Input
Re-Lvling Speed Re-Leveling Speed Input
Rescue Operation Rescue Operation Input
Run Down Run Down Input
Run Up Run Up Input
Run Run Input
S-curve Select 0 S-curve Select 0 Input
S-curve Select 1 S-curve Select 1 Input
Ser2 Insp Ena Ser2 Insp Enable Input
Speed Limit Down Speed Limit Down
Speed Limit Up Speed Limit Up
Timer function Timer function
Up/Down Up/Down Input
C2 Parameter
Choice
Description
