5 Programming
24 MAGNETEK HPV1000 AC Elevator Drive Technical Manual
Table 9 C3 Logic Outputs
Table 10 Logic Output Choices
C3 Parameter Name Description
Default
Logic output P1 Terminal P1 - C1 Function Selection (photocoupler) Not Used
Logic output P2 Terminal P2 - C2 Function Selection (photocoupler) Not Used
Relay M1-M2 Terminal M1 - M2 Function Selection (relay) Not Used
Relay M3-M4 Terminal M3 - M4 Function Selection (relay) Not Used
Relay M5-M6 Terminal M5 - M6 Function Selection (relay) Not Used
C3 Choice Description
Auto Brake
Auto Brake Output (uses encoder feedback to
ensure motor is stationary before setting)
BaseBlock NO Base Block output Normally Open
BaseBlock NC Base Block output Normally Closed
Brake Pick
Brake Pick Output (uses run signaling/timers to set
the brake)
Close Contact Motor Contactor output
DBR Trans Flt Dynamic Braking Transistor Fault
DC Bus Undervolt DC Bus Undervolt Fault
Door Zone Door Zone Output
Drive Ready Drive Ready to Run
Dur Flt Restart Drive fault being reset
During Run 1 Output closes when the drive is outputting a voltage
During Run 2
Output closes when the drive is outputting a
frequency
Fan Alarm Internal cooling fan alarm
Fault Drive in a faulted state
Input Ph Loss Input Phase Loss detected
LightLoadDetStat Light Load Direction Detection Status
LightLoadDirect Light Load Direction
Maintenance Drive requires maintenance
Minor Fault A Minor fault is active
Motor Overload Motor Overload fault active
Not Used Output not used
Overheat Alarm Motor or drive over temperature alarm active
Ovld Shdwn Alm Overload shutdown alarm active
Regenerating
<3>,
<4>
Drive is running and regenerating (not motoring)
Reset Cmd Active Fault Reset input active
Reverse Dir Lift traveling in reverse direction (down)
SafeDisable Stat Safe Disable Status
Spd Detection 3 Speed Detection 3
Spd Detection 4 Speed Detection 4
Spd Ref Release Speed Reference Release active
Spd Reg Release Speed Regulator Release active
SRef/Out Agr 1 Speed Reference Agree 1
SRef/Out Agr 2 Speed Reference Agree 2
SRef/Set Agr 1 Speed User Set Agree 1
SRef/Set Agr 2 Speed User Set Agree 2
Speed Dev Low
<3>, <4>
Speed Deviation low active
Torque Detect 1 Torque Detect 1
Torque Detect 2 Torque Detect 2
Torque Limit
<2>, <3>, <4>
Drive in Torque Limit
Zero Speed Zero speed output
! BaseBlock NC Base Block output Normally Open (Inverse)
! BaseBlock NO Base Block output Normally Closed (Inverse)
! Brake Pick
Brake Pick Output (uses run signaling/timers to set
the brake) (Inverse)
! Close Contact Motor Contactor output (Inverse)
! Drive Ready Drive Ready to Run (Inverse)
! DBR Trans Flt Dynamic Braking Transistor Fault (Inverse)
! DCBus Undervlt DC Bus Undervolt Fault (Inverse)
! Door Zone Door Zone Output (Inverse)
! During Run 1
Output closes when the drive is outputting a
voltage (Inverse)
! During Run 2
Output closes when the drive is outputting a
frequency (Inverse)
! Fan Alarm Internal cooling fan alarm (Inverse)
! Fault Drive in a faulted state (Inverse)
! Input PH Loss Input Phase Loss detected (Inverse)
! LiteLoadDetSta Light Load Direction Detection Status (Inverse)
! LiteLoadDirect Light Load Direction (Inverse)
! Maintenance Drive requires maintenance (Inverse)
! Minor Fault A Minor fault is active (Inverse)
! Motor Overload Motor Overload fault active (Inverse)
! Overheat Alarm
Motor or drive over temperature alarm active
(Inverse)
! Ovld Shdwn Alm Overload shutdown alarm active (Inverse)
! Regenerating
<3>, <4>
Drive is running and regenerating (Inverse)
! ResetCmd Activ Fault Reset input active (Inverse)
! Restart Enable Output active unless drive fault auto reset occurring
! Reverse Dir Lift traveling in reverse direction (down) (Inverse)
! SafeDisablStat Safe Disable Status
! Spd Ref Rls Speed Reference Release active (Inverse)
! Spd Reg Rls Speed Regulator Release active (Inverse)
! Speed Dev Low
<3>, <4>
Speed Deviation low active (Inverse)
! SRef/Out Agr 1 Speed Reference Agree 1 (Inverse)
! SRef/Out Agr 2 Speed Reference Agree 2 (Inverse)
! SRef/Set Agr 1 Speed User Set Agree 1 (Inverse)
! SRef/Set Agr 2 Speed User Set Agree 2 (Inverse)
! Torque Limit
<2>, <3>, <4>
Drive in Torque Limit (Inverse)
! Trq Det 1 N.O. Torque Detect 1 (Inverse)
! Trq Det 2 N.O. Torque Detect 2 (Inverse)
! Zero Speed Zero speed output (Inverse)
<2> Parameter accessible in Open Loop Vector control mode
<3> Parameter accessible in Closed Loop Vector control mode
<4> Parameter accessible in PM Closed Loop Vector control mode
<5> Default is dependent on drive model number
C3 Choice Description
