5 Programming
MAGNETEK HPV1000 AC Elevator Drive Technical Manual 31
Table 16 POWER DATA D2 Submenu
D2 Parameter Name
<1> Parameter accessible in V/f control mode
<2> Parameter accessible in Open Loop Vector control mode
<3> Parameter accessible in Closed Loop Vector control mode
<4> Parameter accessible in PM Closed Loop Vector control mode
<6> Only available in Alternate Navigation menu. Contact Magnetek for details.
Description
Units
DC Bus Voltage
DC Bus Voltage:
Displays the measured DC bus voltage.
VDC
Motor Current
Output Current:
Displays the measured output current to the motor.
A
Motor Voltage
Output Voltage:
Displays the output voltage to the motor.
VA C
Motor Freq Displays the output frequency to the motor. Hz
Torque
Reference
<2>, <3>, <4>
Torque Reference:
Displays the internal torque reference.
% of rated torque
<2>, <3>, <4>
Power Output
Output Kilowatts:
Displays the output power (this value is calculated internally).
kW
Motor Overload
Motor Overload Level:
Shows the value of the motor overload detection accumulator. 100% is equal to the
Motor Overload detection level.
% of motor amp rating
Drive Overload
Drive Overload Level:
Displays the level of the drive overload detection level. A value of 100% is equal to the
Drive Overload detection level
% drive amp rating
Current PeakHold
Current Peak Hold:
Displays the highest current value that occurred during a ride.
A
Heatsink Temp
Heatsink Temperature:
Displays the heatsink temperature.
C
Drv Elapsed Time
<6>
Drive Elapsed Time:
Displays the cumulative operation time of the drive. The value for the cumulative
operation time counter can be reset. Contact Magnetek for details. The maximum
number displayed is 99999, after which the value is reset to 0.
Hours
Fan Elapsed Time
<6>
Fan Elapsed Time:
Displays the cumulative operation time of the cooling fan. This value can be reset.
Contact Magnetek for details. This value will reset to 0 and start counting again after
reaching 99999.
Hours
Fan Life Mon
<6>
Fan Life Monitor:
Displays main cooling fan usage time in as a percentage of its expected performance
life. This value can be reset. Contact Magnetek for details. The fan should be replaced
when this monitor reaches 90%.
% of expected operation time
Cap Life Mon
<6>
Capacitor Life Monitor:
Displays main circuit capacitor usage time in as a percentage of their expected
performance life. The capacitors should be replaced when this monitor reaches 90%.
This value can be reset. Contact Magnetek for details.
% of expected operation time
IGBT Life Mon
<6>
IGBT Life Monitor:
Displays IGBT usage time as a percentage of the expected performance life. The IGBTs
should be replaced when this monitor reaches 90%. This value can be reset. Contact
Magnetek for details.
% of expected operation time
Max Accel Amps
Maximum Current at Acceleration:
Shows the maximum current that occurred during acceleration.
A
Max Decel Amps
Maximum Current at Deceleration:
Shows the maximum current that occurred during deceleration.
A
Max Run Amps
Maximum Current at Run:
Shows the maximum current that occurred during ride at top speed.
A
Slip Comp Value
<1>, <2>
Slip Compensation Value:
Shows the slip compensation value.
%
<1>, <2>
Flux Position
Flux Position:
Displays the angular position of the PM flux position. This number is dependent on the
setting of Enc Z-Pulse Offs (A5).
Deg
PG Counter
Pulse Generator Counter:
Displays the number of pulses for speed detection.
PPR
