Engineered XLTX Transmitter Instruction Manual
December 2016
Page 26 of 49
Setting Timeout to 0 disables transmitter timeout.
4.2.2.5 Backlight Timeout
The backlight timeout setting controls the amount of time that the backlight will stay on after a
command is pressed before it automatically shuts off.
Backlight Timeout can be set from 1 to 30 seconds.
Setting Timeout to “Disabled” will disable the backlight.
Setting Timeout to “Always On” sets the backlight to be on continuously while the transmitter is on
and active.
NOTE: Leaving the backlight on longer will decrease the battery run time and will require more
frequent battery replacement (or recharges for optional rechargeable battery packs).
4.2.2.6 Password Enable
This setting enables or disables the requirement of entering a password into the transmitter to
enter Setup Mode.
When the disabled setting is selected the user will go directly into Setup Mode without being
prompted to enter a password.
Magnetek strongly recommends enabling the Setup Mode password setting to prevent
unauthorized or accidental changes to parameters.
NOTE: The unit is shipped with the password requirement enabled and utilizing the factory
default password.
4.2.2.7 Change Password
This allows the user to change the password needed to enter the Setup Mode.
The password must consist of 4 digits.
4.2.2.8 IR Configuration Receiver
The IR Cfg Recv function in the setup allows the transmitter to link to a compatible receiver by
using IR (contact the factory to determine if your receiver is compatible), and automatically set up
the channel and access code to match the linked compatible receiver.
After selecting this option, point the IR window of the transmitter at the desired receiver to control
and momentarily press the OFF-ON-Start toggle to the Start position and release. The graphic
user interface will display “Attempting” while scanning for the receiver’s IR signal. If the receiver is
in range and IR link is made, the message will change to “Success”.
WARNING
DO NOT ASSUME THE POWER IS OFF IN THE RECEIVER BECAUSE THE
TRANSMITTER IS TURNED OFF. FAILURE TO FOLLOW THIS WARNING COULD
RESULT IN SERIOUS INJURY OR DEATH AND DAMAGE TO EQUIPMENT.
