Engineered XLTX Transmitter Instruction Manual
December 2016
Page 35 of 49
WARNING
THE ACCESS CODES IN THE RECEIVER ARE UNIQUE AND FACTORY PRESET. DO NOT CHANGE
THESE ACCESS CODES UNLESS YOU ARE REPLACING AN EXISTING RECEIVER AND ITS ACCESS
CODE. CHANGING THIS CODE COULD MAKE IT COMMON WITH ANOTHER RECEIVER ACCESS
CODE, WHICH COULD MOVE OTHER EQUIPMENT. NO TWO SYSTEMS IN ANY LOCATION SHOULD
EVER HAVE THE SAME ACCESS CODES INDEPENDENT OF FREQUENCY. FAILURE TO FOLLOW
THIS WARNING COULD RESULT IN SERIOUS INJURY OR DEATH, AND DAMAGE TO EQUIPMENT.
RF Channel
The RF channel is user-selectable through the pull-down menu. This function is used to prevent
interference with other radio devices. The user-selectable channels for 400 MHz, 900 MHz and
2.4 GHz systems are 1 through 32. See Section 6.2 for channel frequency details.
NOTE: If using the optional RCP software on transmitters NOT equipped with the graphic user
interface, the channel settings will read from the dip switch positions and not from memory when
the channel from memory override function is not enabled. The RF channel set by the optional
RCP software will not be used unless the memory override dip switch is set to ON. When the RF
channel from memory override is NOT enabled, the dip switch positions set the RF channel used
by the Transmitter.
Inactivity Timeout
The transmitter can be set to turn off after a period of time when no controls are activated. To
restart the transmitter, the OFF-ON-START switch must be cycled through the start procedure.
The factory default setting for the inactivity timeout is 15 minutes.
RF Power
The RF transmitting power of the unit is user-selectable through the pull-down menu. This
function is used to reduce the operating range of the transmitter from the equipment being
operated. The user-selectable options for RF power are MAX, 50%, 25% and MIN.
Activate Password
The password is used to restrict access to the configuration menu on the XLTX. Having an active
password prevents accidental changes to the transmitter.
Please familiarize yourself with this section before programming your password.
If you choose to enable the password function, you can create a new password by selecting a
four digit numerical password using numbers from 0 to 9. Be sure to write this password down in
a safe place for future reference.
