Battery Charger Instruction Manual – December 2015
8
2) Single Charger Instructions
1. Plug charger power supply adapter into 100-240VAC 47-
63Hz power source. Plug the adapter jack in the charger
base connection labeled “IN” as show in Figure 2. The
“POWER” light will come on BLUE, indicating the unit is
receiving power.
Figure 2
2. Insert the battery into the slot until the battery settles firmly in
place. The battery label MUST be facing upward with the
tab facing out, as shown in Figure 3
.
Battery Charger Instruction Manual – December 2015
5
1) Warnings and Cautions
WARNING, CAUTION, and Note statements are used throughout
this manual to emphasize important and critical information. You
must read these statements to help ensure safety and to prevent
product damage. The statements are defined below.
WARNING
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided,
could result in minor or moderate injury. It may also be used to alert
against unsafe practices.
NOTE: A note statement is used to notify users of installation, operation,
programming, or maintenance information that is important, but not
hazard-related.
