© Copyright Mahindra & Mahindra Ltd. 012016
2-9
Fuse No
Fuse Rating
Circuit
5
Spare Fuse
6
Spare Fuse
7
Spare Fuse
8 60A
Battery — 1
9 60A
Battery — 2
10 60A EC Mini Fuse
11
Glow Plug Relay
12
Spare Fuse
13
Spare Fuse
14
Spare Fuse
15 30A
ABS Solenoid / Condenser Fan
16 15A Brake switch
17 15A
AC Comp Clutch
18 10A HFM
19
Spare
20 10A
AC Relay/GNS
21
Spare
22 5A
CBS/ISS
23
Spare
24 15A Horn
25 15A EGR
26 15A
Front Fog Lamp
27 10A
EMS Battery-2
28 15A Low Beam
29 10A
EMS Battery-1
30 15A
High Beam
Relay No
Circuit
31
Cooling Fan Low Relay
32
Cooling Fan High Relay
33
Spare
34
GNS Relay
35
Spare
36
AC Compressor Relay
37
Head lamp LO Beam Relay
38
Fog Lamp Relay
39
Head lamp HI Beam Relay
40
Horn Relay
41
ECU Main Relay
42
Starter Relay
43
Spare
44
Spare
45
Glow Plug Relay
46
Spare
2.5.2 Instrument Panel Fuse Box
• Unlock the steering tilt lever (push it down)
• Remove the two screws of the shroud below the steering
column
• Open the shroud outward to access the instrument panel fuse
box
GENERAL
