Mahindra 2016 Scorpio User Manual

2-8
© Copyright Mahindra & Mahindra Ltd.012016
2.5.1 Engine Compartment Fuse Box
W12B31
W12B06
The engine compartment fuse box is located adjacent to vehicle
battery. Follow the below steps to remove the fuse cover;
• Slightly press/nudge the fuse cover towards the vehicle LHS and
remove the left snap lock
• Further, push top cover towards vehicle RHS and remove/pull
the cover completely
W12B38
SPARE
FUSE
CAB BATT- 2
60 A
ABS
MOTOR
40A
EMS MAI N
GLOW P LUG
RELAY F USE
RELAY I / P
30 A
STARTER
SOLENOI D
60 A
EC MI NI
FUSE B+
60 A
60 A
SPARE
HORN 1 5A
A/C RELAY/ GNS
10 A
CBSB/WIF/ ESS
5A
SPARE
EGR/FMU/ BPA
15A
FRONT FOG LAMP
15A
EMS BATT-2
10A
LOW BEAM
15A
EMS BATT-1
10A
HIGH BEAM 15 A
SPARE
HFM 10A
AC COMP
CLUTCH 1 5A
BRAKE SWITCH
15A
ABS/CONDENSOR
FAN 30A
GLOW PLUG
RELAY
STARTER
RELAY
COOLING
FAN HIGH
RELAY
COOLING
FAN LOW
RELAY
HORN
RELAY
HIGH
RELAY
LOW
RELAY
FOG
RELAY
AC
COMP
RELAY
SPARE
RELAY
SPARE
RELAY
GNS
RELAY
CAB BATT- 1
60 A
CAB BATT- 3
60 A
SPARE
FUSE
SPARE
FUSE
SPARE
FUSE
SPARE
FUSE
SPARE
FUSE
ECU
MAI N
RELAY
SPARE
RELAY
SPARE
RELAY
SPARE
RELAY
BEAM
LAMP
BEAM
1 2 3 4 5 6 7
45 46
4443
37 38
39 40
33 34
41 42
3
2
3
1
15 16 17 18 19 20 21 22
30 29 28 27 26 25 24 23
35 36
8 9 10 11 12 13 14
W12B39
Fuse No
Fuse Rating
Circuit
1 60A
Battery — 3
2 40A ABS
3 60A Starter Solenoid
4 30A
EMS Relay
