Maico easyScreen User Manual

Operation Manual easyScreen
8508935 Rev. 4
65
04/04/2019
5.13.2.4 Proceed to Test
Select the Test button in the bottom control bar to proceed with testing this patient.
5.13.2.5 View Test List
Select the Test List button in the bottom control bar of the Patient information
screen to see a list of tests performed on this patient.
Figure 78
The test list is sorted chronologically with the most recent test
at the top (Figure 78). Each row represents one test.
If more than 8 tests are saved then use the Up and
Down arrow buttons in the bottom control bar to page
through the list.
You can select one or more tests from this list and print them
(see section 5.13.3.2).
Figure 79
Each row in the View Test List screen shows the following
information:
• Result symbol for Pass, Refer or Incomplete
• Test ear symbol for Right, Left or Both ears
• Test date & time
• Technology type (ABR, DPOAE or TEOAE)
5.13.2.6 Review Test Details
Select one of the tests in the list to view its details. See sections 5.10 to 5.11.5 for
descriptions of the information displayed in the View Details screens.
5.13.2.7 View Test Fields
Figure 80
Select the View Test Fields button in the bottom bar of
the View Details screen to view the test fields. This screen will
be available only if the Test Fields option is enabled on the
device via the HearSIM PC application.
The test fields cannot be edited on the easyScreen. If edits are
needed, the test data must be transferred into the HearSIM
PC application and the edits can be made there.
