Makita JR3051T Repair Manual

3 / 32
2 CAUTION
Repair the machine in accordance with "Instruction manual" or "Safety instructions".
Follow the instructions described below in advance before repairing:
 Wear gloves.
 In order to avoid wrong reassembly, draw or write down where and how the parts are assembled, and what the parts are.
It is also recommended to have boxes ready to keep disassembled parts by group.
 Handle the disassembled parts carefully. Clean and wash them properly.
3 NECESSARY REPAIRING TOOLS
Code No.
Description
Use for
1R034
Ring 12-60-15
press-fitting Ball bearings 6001LLU and 608ZZ
1R049
Drill chuck removal wedge 15
fixing Blade clamp section
1R269
Bearing puller small
removing Ball bearings 6001LLUand 608ZZ
1R291
Retaining ring pliers S and R
removing/ assembling Retaining ring S-12
1R296
Spring pin extractor 1.5
removing Switch Lead wires
1R312
Hammer clamping vise
fixing the machine
1R370
Ring terminal setting jig
assembling Ring terminal
1R461
Grip for spring pin extractor
using with 1R296

Makita JR3051T Specifications

General

Power Source	Corded
Amperage	12 A
Strokes Per Minute	0-3, 000 SPM
Tool Weight	7.3 lbs
Voltage	120 V
Tool Length	17-3/4 inches
Max. Cutting Capacity in Wood	10 inches
Max. Cutting Capacity in Steel Pipe	5-1/8 inches
