Makita JR3051T Repair Manual

4 / 32
4 LUBRICANT AND ADHESIVE APPLICATION
Description
Amount
Makita grease FA. No.2
Apply a little unless specified in the figure.
Makita grease R No.00
Apply a little unless specified in the figure.
Fig.1
5 TIGHTENING TORQUE SPECIFICATIONS
Parts to fasten
Fastener
Q’ty
Tightening torque
(N∙m)
Bearing retainer 80
↔
Gear housing
Hex. socket head bolt M4x12
2
3.0 - 3.5
Shoe
↔
Gear housing
Hex. socket head bolt M6x20
1
6.3 - 6.8
15g
12g
1g

Makita JR3051T Specifications

General

Power Source	Corded
Amperage	12 A
Strokes Per Minute	0-3, 000 SPM
Tool Weight	7.3 lbs
Voltage	120 V
Tool Length	17-3/4 inches
Max. Cutting Capacity in Wood	10 inches
Max. Cutting Capacity in Steel Pipe	5-1/8 inches
